Walk-In Cooler service, repair and install should be done by a certified contractor. This is an enclosed storage space with refrigerated temperatures above 32 degrees Fahrenheit. Most unit can be walked in and has a total chilled storage area of less than 3,000 square feet. The low side of a walk-in Cooler refrigeration system is where the cooling takes place. Heat is absorbed into the refrigerant inside the evaporator by blowing air across the evaporator coil. This heat eventually travels to the outdoor condenser, where it is then rejected into the atmosphere. The low pressure side of commercial refrigeration system can include any of the following components.
- Forced-draft Evaporator – Is a unit equipped with a fan, that blows air over the coil’s compact refrigerant tubes and fins. The surrounding heat would then absorbed into the refrigerant.
- Suction line – This tube is where the low temperature refrigerant gas travels back to the compressor.
- Suction line filter-driers – These are often mounted in a suction line to prevent foreign particles and moisture from entering the compressor. Replacement of these filter driers is necessary following a compressor burnout.
- Accumulator – This consist of a tank with a reservoir on the bottom for liquid refrigerant, an inlet and outlet on top for vapor refrigerant. This design ensures that only vapor refrigerant is drawn out of the accumulator and through the rest of the suction line into the compressor.
- Pressure switch – This device protects the compressor by shutting it down whenever the refrigerant is low within the system.
- EPR valve – This consist of an adjustable spring, a bellows or diaphragm, a needle and a seat. Two opposing force working together to operate evaporator pressure regulators. An EPR may also be called an open on rise of inlet pressure valve.
- CPR valve – This is installed ahead of the compressor inlet to protect the compressor from excessive suction line pressure. As suction line pressure rises, the CPR closes reducing the flow of refrigerant vapor.
Within the walk-in cooler bacteria grows faster in temperature range between 40 deg and 140 deg F. This is generally call the DANGER ZONE. Food safety authority advice that meat, poultry, milk etc should never be left out of refrigeration over two hours and one hour if temperature is about 90 deg F.
Note: Commercial refrigeration/ Walk-in cooler service repair and install is extremely important to have them done by a certified refrigeration contractor in order for the system to reach health and safety recommended temperature. Refrigeration contractor must comply with health and safety rules and regulation practices.
Commercial refrigeration systems maybe custom designed and constructed to meet the specific needs of the customer. These systems may use any of a number of methods to achieve the desired cooling capacities under the expected operating condition.
